Gigabyte GA-78LMT-USB3 R2 (Rev. 1.0)

1. Support for AMD AM3+ processor
2. Support for AMD AM3 Phenom™ II processor / AMD Athlon™ II processor

1. HyperTransport™ 3.0
2. Support up to 5200MT/s

1. North Bridge: AMD 760G
2. South Bridge: AMD SB710

1. 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory

* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.

1. Dual channel memory architecture
2. Support for 1600(O.C.)/1333/1066 MHz memory modules

1. 1 x D-Sub port, supporting a maximum resolution of 1920×1200
2. 1 x DVI-D port, supporting a maximum resolution of 1920×1200

* The DVI-D port does not support D-Sub connection by adapter.

1. 1 x HDMI port, supporting a maximum resolution of 1920×1200

* Simultaneous output for DVI-D and HDMI is not supported.

1. Support for DirectX 10

1. Realtek® ALC892 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel

* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

1. Support for S/PDIF Out

1. Realtek® GbE LAN chip (10/100/1000 Mbit)

1. 1 x PCI Express x16 slot, running at x16
2. 1 x PCI Express x1 slot

(The PCI Express slots conform to PCI Express 2.0 standard.)

1. 1 x PCI slot

1. 1 x IDE connector supporting ATA-133/100/66/33
2. 6 x SATA 3Gb/s connectors
3. Support for RAID 0, RAID 1, RAID 10, and JBOD

1. 8 USB 2.0/1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

VIA® VL805 chip:

1. 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

1. 1 x 24-pin ATX main power connector
2. 1 x 8-pin ATX 12V power connector
3. 6 x SATA 3Gb/s connectors
4. 1 x IDE connector
5. 1 x CPU fan header
6. 1 x system fan header
7. 1 x front panel header
8. 1 x front panel audio header
9. 1 x S/PDIF Out header
10. 1 x USB 3.1 Gen 1 header
11. 2 x USB 2.0/1.1 headers
12. 1 x serial port header
13. 1 x parallel port header
14. 1 x Clear CMOS jumper

1. 1 x PS/2 keyboard/mouse port
2. 1 x D-Sub port
3. 1 x DVI-D port
4. 1 x HDMI port
5. 2 x USB 3.1 Gen 1 ports
6. 4 x USB 2.0/1.1 ports
7. 1 x RJ-45 port
8. 3 x audio jacks (Line In, Line Out, Mic In)

1. iTE® I/O Controller Chip

1. System voltage detection
2. CPU/System temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System fan fail warning
6. CPU/System fan speed control

1. 2 x 32 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS™
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for EasyTune

* Available functions in EasyTune may differ by motherboard model.

1. Support for Smart Recovery2
2. Support for Auto Green
3. Support for ON/OFF Charge

1. Norton® Internet Security (OEM version)

1. Support for Windows 7/XP

1. Micro ATX Form Factor; 24.4cm x 24.4cm
